Analog and Power Test System
FPVI10_PLUS
FPVI10_PLUS
Analog, Digital to Power Discrete
Floating Power Dual VI Source Measure Module for STS8200
Key Features
- Full floating two channels VI SMU
- Four Quadrant Capability
- 8 Force/Measure Voltage Ranges:
- ±100V, ±50V (max. output 40V), ±20V, ±10V, ±5V, ±2V, ±1V, ±100mV (measure only)
- 7 Force/Measure Current Ranges:
- ±10A (pulse), ±1, ±100mA, ±10mA, ±1mA, ±100uA, ±10uA (measure only)
- Independent per-pin real time data processing including Max., Min., AVG and Trigger
